1µV Resolution

RMS Noise of only ±750nV at 100Hz

The Izze-Racing 24-Bit ADC-to-CAN Amplifier is specifically designed to condition, amplify, and measure the voltage signal from a strain gauge or load cell and output the measured voltage via CAN with class-leading precision, accuracy, and noise.

The amplifier measure's differential voltage's up to 32.7mV with a resolution of 1µV and RMS noise of only ±750nV at a sampling frequency of 100Hz. Bridge excitation is provided by the amplifier and the output signal is digitally transmitted via CAN.

Update Frequency
CAN ID: (Default = 0x4E2)

Seamless Integration into CAN-Capable Data Acquisition Systems

MoTeC CAN

Configuration:

24-Bit ADC-to-CAN Strain Gauge and Load Cell Amplifier

Designed, Machined, and Assembled in the USA

Izze Racing Made in USA

Datasheet and Ordering

FSAE

Discounts for FSAE teams, contact us for details

Datasheet

Izze Racing Strain Gauge and Load Cell Datasheet
Izze Racing Strain Gauge and Load Cell Amplifier Resolution
Izze Racing Strain Gauge and Load Cell Amplifier Noise

Return Policy & Warranty

The Amplifiers come with a 30-Day return policy and have a 1-year warranty from manufacturing defects. If there is ever an issue, please contact us; customer satisfaction & support is paramount to us.

Update Rate of up to 830Hz

Video of Real-Time Wheel Loads at VIR

Amplifier Wiring Diagram

Izze Racing Strain Gauge and Load Cell Amplifier with MoTeC Data Logger
Izze Racing Strain Gauge and Load Cell Amplifier Wiring Diagram
Izze Racing Strain Gauge and Load Cell Amplifier with MoTeC Data Logger
Izze Racing Strain Gauge and Load Cell Amplifier 830Hz Update Rate

AiM CAN

Configuration:
